IMO PRECISION CONTROLS - SRF-1C-SL-5VDC - General Purpose Relay, SRF Series, Power, Non Latching, SPDT, 5 VDC, 1 A
- Contact Configuration: SPDT
- Coil Voltage: 5VDC
- Contact Current: 1A
- Product Range: SRF Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 240VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 30VDC
- Contact Material: Silver Nickel
- Coil Resistance: 120ohm
- SVHC: No SVHC (07-Jul-2017)
- Approval Bodies: CUR
- Coil Current: 44.7mA
- Coil Operating Lower Percent Limit: 75%
- Coil Operating Upper Percent Limit: 130%
- Coil Voltage VDC Nom: 5V
- Contact Current AC Max: 2A
- Contact Current DC Max: 2A
- Contact Current Max: 2A
- Contact Voltage AC Max: 120V
- Contact Voltage AC Nom: 120V
- Contact Voltage DC Max: 60V
- Contact Voltage DC Nom: 60V
- DC Coil Power: 200mW
- External Depth: 10.9mm
- External Height: 12mm
- External Length / Height: 12mm
- External Width: 15.7mm
- Nom Operating Power: 200mW
- Operating Temperature Max: 55°C
- Operating Temperature Min: -25°C
- Operating Time: 10ms
- Relay Type: Power - General Purpose
- Release Time: 5ms
