CELDUC - SKA20420 - Solid State Relay, 4 A, 275 Vrms, PCB, Through Hole, Zero Crossing
- Contact Configuration: -
- Load Current: 4A
- Operating Voltage Max: 275Vrms
- Relay Mounting: PCB
- Relay Terminals: Through Hole
- Switching Mode: Zero Crossing
- Operating Voltage Min: 12Vrms
- Control Voltage Min: 4VDC
- Control Voltage Max: 30VDC
- Product Range: -
- SVHC: No SVHC (07-Jul-2017)
- Control Voltage DC Max: 30VDC
- Control Voltage DC Min: 4VDC
- Control Voltage Range: 4V DC to 30V DC
- Control Voltage Type: DC
- External Depth: 10.2mm
- External Length / Height: 43.2mm
- External Width: 25.4mm
- Height: 43.2mm
- I2t: 50s
- Input Voltage: 4V DC to 30V DC
- Insulation Resistance: 1kohm
- Isolation Voltage: 4kV
- Load Current Min: 5mA
- Load Current RMS Max: 4A
- Load Voltage Range: 12V AC to 275V AC
- Operating Current DC: 3mA
- Operating Frequency: 440Hz
- Operating Temperature Max: 80°C
- Operating Temperature Min: -40°C
- Operating Voltage Range: 12Vrms to 275Vrms
- RMS Load Current Min: 5mA
- RMS Load Voltage Max: 275VAC
- RMS Load Voltage Min: 12VAC
- Turn Off Time: 10ms
- Turn On Time: 10ms
