SCHNEIDER ELECTRIC - RSB2A080JD - General Purpose Relay, RSB Series, Interface, DPDT, 12 VDC, 8 A
- Contact Configuration: DPDT
- Coil Voltage: 12VDC
- Contact Current: 8A
- Product Range: Zelio Series
- Relay Mounting: Socket
- Coil Type: -
- Contact Voltage VAC: 250VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: 28VDC
- Contact Material: Silver Alloy
- Coil Resistance: 360ohm
- SVHC: No SVHC (07-Jul-2017)
- Approvals & Standards: CSA, UL
- Average Power Consumption: 450mW
- Coil Voltage VDC Nom: 12V
- Contact Current Max: 8A
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Max: 300V
- External Depth: 29mm
- External Height: 15.7mm
- External Width: 12.5mm
- Relay Type: Interface
