TDK-LAMBDA - PXD10-24WS-05 - Isolated Through Hole DC/DC Converter, ITE, 4:1, 10 W, 1 Output, 5 V, 2 A
- No. of Outputs: 1 Output
- Output Power Max: 10W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 2A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: PXD Series
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 25.4mm
- Height: 10.2mm
- Depth: 50.8mm
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CE, CSA, EN, UL
- Approvals & Standards: CE, CSA, UL
- Efficiency: 80%
- Isolation Voltage: 1.6kV
- No. of Outputs: 1Outputs
- Output Power (Pout): 10W
- Power Rating: 10W
- Supply Voltage: 24V
