MEAN WELL - PLN-20-24 - LED Driver, Active PFC, 19.2 W, 24 V, 800 mA, Constant Current, 90 V
- Output Power Max: 19.2W
- Output Voltage Max: 24V
- Output Current: 800mA
- LED Driver Mode: Constant Current
- Input Voltage Min: 90V
- Input Voltage Max: 277V
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- Depth: 28mm
- Dimming Control Type: PWM
- Efficiency: 82%
- Height: 28mm
- Length: 148.5mm
- No. of Channels: 1Channels
- No. of Outputs: 1Outputs
- Operating Temperature Max: 60°C
- Operating Temperature Min: -30°C
- Operating Temperature Range: -30°C to +60°C
- Output Power: 19.2W
- Output Voltage: 24V
- Power Supply Mounting: Chassis
- Power Supply Output Type: Adjustable, Fixed
- Termination Style: Flying Leads
- Width: 38.5mm
