MAL210119223E3 Cap, 22000µF, 100V, Alu Elec, Screw Vishay

VISHAYUGS :MAL210119223E3 Code de commande:8820945

Prix:
Prix ​​promotionnel€115,32

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (75 unité)

Documents et téléchargements

description

VISHAY - MAL210119223E3 - Electrolytic Capacitor, Screw, 22000 µF, 100 V, ± 20%, Screw, 15000 hours @ 85°C

  • Capacitance: 22000µF
  • Voltage Rating: 100V
  • Product Range: 101 PHR-ST Series
  • Lifetime @ Temperature: 15000 hours @ 85°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Screw
  • Diameter: 65mm
  • Lead Spacing: 28.5mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Height: 105mm
  • ESR: 0.011ohm
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • AC Ripple Current @ 100Hz: 8A
  • AC Ripple Current @ 20kHz: 8A
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Mounting: Panel
  • Climatic Category: 40/085/86
  • External Length / Height: 105mm
  • Leakage Current: 4.4mA
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +85°C
  • Operating life Time: 15000h
  • Ripple Current AC: 8A
  • Ripple Current Frequency: 100Hz
  • Ripple Current Temperature: 85°C
  • Tolerance +: 0.2%
  • Tolerance -: 0.2%
  • Voltage Rating DC Max: 100V
  • Voltage Rating V DC: 100V
