JTK1524D15 Converter, DC/DC 15w, +/-15V XP Power

XP POWERUGS :JTK1524D15 Code de commande:1738210

Prix:
Prix ​​promotionnel€54,10

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Rupture de stock

Documents et téléchargements

description

XP POWER - JTK1524D15 - Isolated Through Hole DC/DC Converter, 4:1 Input, ITE, 4:1, 15 W, 2 Output, 15 V, 500 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 15W
  • Output Voltage - Output 1: 15V
  • Output Current - Output 1: 500mA
  • Output Voltage - Output 2: -15V
  • Output Current - Output 2: 500mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: JTK Series
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 36V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 25.4mm
  • Height: 9.9mm
  • Depth: 25.4mm
  • SVHC: No SVHC (15-Jan-2018)
  • Efficiency: 89%
  • External Depth: 25.4mm
  • External Length / Height: 9.9mm
  • External Width: 25.4mm
  • Isolation Voltage: 1.6kV
  • No. of Outputs: 2Outputs
  • Power Rating: 15W
  • Supply Voltage: 24V
