XP POWER - JHM0612D15 - Isolated Through Hole DC/DC Converter, Medical, 2:1, 6 W, 2 Output, 15 V, 200 mA
- No. of Outputs: 2 Output
- Output Power Max: 6W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 200mA
- Output Voltage - Output 2: -15V
- Output Current - Output 2: 200mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 10V
- Input Voltage DC Max: 17V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.32mm
- Height: 10.4mm
- Depth: 31.75mm
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CSA 22.2 No. 60601, IEC 60601, UL 60601
- Approvals & Standards: CSA 22.2 No. 60601, IEC 60601, UL 60601
- Efficiency: 84%
- External Depth: 20.32mm
- External Length / Height: 10.4mm
- External Width: 31.75mm
- Isolation Voltage: 5kV
- No. of Outputs: 2Outputs
- Operating Temperature Max: 60°C
- Operating Temperature Min: -20°C
- Power Rating: 6W
- Weight: 20g
