XP POWER - JCP4012T0512 - Isolated Through Hole DC/DC Converter, Metal Case, ITE, 2:1, 40 W, 3 Output, 5 V, 6 A
- No. of Outputs: 3 Output
- Output Power Max: 40W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 6A
- Output Voltage - Output 2: 12V
- Output Current - Output 2: 400mA
- Output Voltage - Output 3: -12V
- Output Current - Output 3: 400mA
- Product Range: JCP Series
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 18V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 50.8mm
- Height: 10.2mm
- Depth: 50.8mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency: 86%
- External Depth: 10.2mm
- External Length / Height: 50.8mm
- External Width: 29.2mm
- Isolation Voltage: 1.5kV
- No. of Outputs: 3Outputs
- Off Load Current: 200mA
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Output Current - Max: 0.4A
- Output Ripple Voltage pk-pk: 75mV
- Output Voltage +: 12V
- Output Voltage -: 12V
- Power Rating: 40W
- Supply Voltage: 12V
