XP POWER - JCL3048S15 - Isolated Through Hole DC/DC Converter, 2:1 Input, ITE, 2:1, 30 W, 1 Output, 15 V, 2 A
- No. of Outputs: 1 Output
- Output Power Max: 30W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 2A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: JCL30 Series
- Input Voltage DC Min: 36V
- Input Voltage DC Max: 75V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 40.64mm
- Height: 10.2mm
- Depth: 50.8mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency: 91%
- External Depth: 40.64mm
- External Length / Height: 11.43mm
- External Width: 50.8mm
- Isolation Voltage: 1.5kV
- No. of Outputs: 1Outputs
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Output Ripple Voltage pk-pk: 75mV
- Power Rating: 30W
- Supply Voltage: 48V
- Weight: 48g
