JAH0224D15 DC/DC Converter, 2W, Dual 15V O/P XP Power

XP POWERUGS :JAH0224D15 Code de commande:1859094

Prix:
Prix ​​promotionnel€24,38

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (77 unité)

Documents et téléchargements

description

XP POWER - JAH0224D15 - Isolated Through Hole DC/DC Converter, 1kV Isolation, ITE, 1:1, 2 W, 2 Output, 15 V, 67 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 2W
  • Output Voltage - Output 1: 15V
  • Output Current - Output 1: 67mA
  • Output Voltage - Output 2: -15V
  • Output Current - Output 2: 67mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: JAH Series
  • Input Voltage DC Min: 21.6V
  • Input Voltage DC Max: 26.4V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 20.32mm
  • Height: 10.16mm
  • Depth: 31.75mm
  • SVHC: No SVHC (15-Jan-2018)
  • Isolation Voltage: 1kV
  • No. of Outputs: 2Outputs
  • Power Rating: 2W
  • Supply Voltage: 24V
