VISHAY - IHLP2525AHER2R2M01 - Power Inductor (SMD), 2.2 µH, 3.75 A, Shielded, 13 A, IHLP-2525AH-01, 6.86mm x 6.47mm x 1.8mm
- Inductance: 2.2µH
- RMS Current (Irms): 3.75A
- Inductor Construction: Shielded
- Saturation Current (Isat): 13A
- Product Range: IHLP-2525AH-01 Series
- Power Inductor Case: 6.86mm x 6.47mm x 1.8mm
- DC Resistance Max: 0.046ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- External Depth: 6.47mm
- External Length / Height: 1.8mm
- External Width: 6.86mm
- Inductor Type: High Current
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
