OMRON - G2RL-14-E DC24 - General Purpose Relay, G2RL Series, Power, Non Latching, SPDT, 24 VDC, 12 A
- Contact Configuration: SPDT
- Coil Voltage: 24VDC
- Contact Current: 16A
- Product Range: G2RL Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 24VDC
- Contact Material: Silver Tin Oxide
- Coil Resistance: 1.44kohm
- Approvals & Standards: CE, UL, VDE
- Coil Current: 16.7mA
- Coil Voltage VDC Nom: 24V
- Contact Current Max: 16A
- Contact Voltage AC Nom: 440V
- Contact Voltage DC Nom: 300V
- External Depth: 29mm
- External Height: 15.7mm
- External Width: 12.7mm
- Nom Operating Power: 400mW
- Relay Type: Power - General Purpose
