G2R-2A DC5 Relay, DPDT, Sealed, 5A, 5VDC Omron

OMRONUGS :G2R-2A DC5 Code de commande:2068201

Prix:
Prix ​​promotionnel€7,06

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Rupture de stock

Documenten en downloads

description

OMRON - G2R-2A DC5 - General Purpose Relay, G2R Series, Power, Non Latching, DPST-NO, 5 VDC, 5 A

  • Contact Configuration: DPST-NO
  • Coil Voltage: 5VDC
  • Contact Current: 5A
  • Product Range: G2R Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 380VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 125VDC
  • Contact Material: Silver Alloy
  • Coil Resistance: 47ohm
  • Approvals & Standards: CSA, UL, VDE
  • Coil Current: 106mA
  • Coil Voltage VDC Nom: 5V
  • Contact Current Max: 5A
  • Contact Voltage AC Nom: 380V
  • Contact Voltage DC Nom: 125V
  • External Depth: 29mm
  • External Height: 25.5mm
  • External Width: 13mm
  • Nom Operating Power: 530mW
  • Relay Type: Power - General Purpose
