description
BLOCK - FL52/15 - PCB Transformer, UI 48 x 26, Encapsulated Safety Isolating, 2 x 115V, 2 x 15V, 52 VA, 50Hz / 60Hz
- Power Rating: 52VA
- Secondary Voltages: 2 x 15V
- Current Rating: 1.73A
- Isolation Transformer Primary Voltages: 2 x 115V
- Plug Type: -
- Product Range: FL Series
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 52VA
- Approval Bodies: CSA, UL, VDE
- External Depth: 49mm
- External Length / Height: 86.5mm
- External Width: 70mm
- Fixing Centres LxW: 75x70
- Flammability Rating: UL94V-0
- Hole Spacing - Length: 53.5mm
- Input Voltage: 115V
- Isolation Voltage: 5kV
- Lead Spacing: 10mm
- Length: 49mm
- Output 2 Voltage Max: 15V
- Output Voltage: 15V
- Pin Length: 5mm
- Pitch Spacing: 15mm
- Primary Voltages: 2 x 115V
- Regulation: 81%
- Secondary Power: 26VA
- Transformer Type: Encapsulated
- Weight: 980g
