BLOCK - FL2/6 - PCB Transformer, UI 30 x 5.5, Encapsulated Safety Isolating, 2 x 115V, 2 x 6V, 2 VA, 50Hz / 60Hz
- Power Rating: 2VA
- Secondary Voltages: 2 x 6V
- Current Rating: 160mA
- Isolation Transformer Primary Voltages: 2 x 115V
- Plug Type: -
- Product Range: FL Series
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 2VA
- Approval Bodies: CSA, UL, VDE
- External Depth: 17.6mm
- External Length / Height: 53mm
- External Width: 44mm
- Fixing Centres LxW: 47.5x37.5
- Flammability Rating: UL94V-0
- Height: 53mm
- Hole Spacing - Length: 35mm
- Input Voltage: 115V
- Isolation Voltage: 5kV
- Lead Spacing: 5mm
- Length: 17.6mm
- Output 2 Voltage Max: 6V
- Output Voltage: 6V
- Pin Diameter: 0.8mm
- Pin Length: 5mm
- Pitch Spacing: 10mm
- Primary Voltages: 2 x 115V
- Regulation: 66%
- Secondary Power: 1VA
- Transformer Type: Encapsulated
- Weight: 115g
