Fel-F115R2112V12 LED, SPLED, Red Forge

FORGEUGS :FEL-F115R2112V12 Code de commande:8738955

Prix:
Prix ​​promotionnel€3,12

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (145 unité)

Documents et téléchargements

description

FORGE - FEL-F115R2112V12 - High Brightness LED, FEL-F115, Red, 635 nm, 3.4 lm

  • Product Range: FEL-F115 Series
  • LED Colour: Red
  • Wavelength Typ: 635nm
  • Viewing Angle: -
  • Luminous Flux @ Test: 3.4lm
  • Forward Current If Max: -
  • Forward Current @ Test: 35mA
  • Forward Voltage @ Test: 12V
  • Luminous Intensity @ Test: -
  • Power Dissipation Pd: -
  • Automotive Qualification Standard: -
  • MSL: -
  • SVHC: No SVHC (07-Jul-2017)
  • Bulb Size: 8mm
  • Dominant Wavelength: 635nm
  • Forward Current If: 35mA
  • Forward Voltage: 12V
  • Forward Voltage VF Max: 12V
  • LED / Lamp Size: 8mm
  • LED Mounting: Panel Mount
  • Lens Shape: Dome
  • Luminance: 3.3cd/m²
  • Luminous Intensity Typ: 3.3lm
  • No. of Pins: 2Pins
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -25°C
  • Operating Temperature Range: -25°C to +80°C
  • Power @ Test: 0.4W
  • Supply Voltage: 12V
  • Voltage Vf Typ: 12VDC
