ERZE10A911 Varistor, Large Surge, Transient, 910V Panasonic

PANASONICUGS :ERZE10A911 Code de commande:2291820

Prix:
Prix ​​promotionnel€0,89

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (77 unité)

Documents et téléchargements

description

PANASONIC - ERZE10A911 - TVS Varistor, 680 V, 895 V, E10, 1.5 kV, Disc 12.5mm, Zinc Oxide Non-Linear Resistor (ZNR)

  • Voltage Rating VAC: 680V
  • Voltage Rating V DC: 895V
  • Product Range: E10 Series
  • Clamping Voltage Vc Max: 1.5kV
  • Varistor Case Style: Disc 12.5mm
  • Varistor Type: Zinc Oxide Non-Linear Resistor (ZNR)
  • Peak Surge Current @ 8/20µs: 4.5kA
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Peak Energy (10/1000uS): 182J
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Operating Temperature Range: -40°C to +85°C
