PANASONIC - EEUEE2G680 - Electrolytic Capacitor, 68 µF, 400 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar
- Capacitance: 68µF
- Voltage Rating: 400V
- Product Range: EE Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 18mm
- Lead Spacing: 7.5mm
- Height: 25mm
- Operating Temperature Min: -25°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 10000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 25mm
- No. of Pins: 2Pins
- Operating Temperature Range: -25°C to +105°C
- Ripple Current AC: 1470mA
- Ripple Current Frequency: 100kHz
