description
PANASONIC - EEEFC0J470AR - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 47 µF, 6.3 V, 1000 hours @ 105°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 47µF
- Voltage Rating: 6.3V
- ESR: -
- Product Range: -
- Lifetime @ Temperature: 1000 hours @ 105°C
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Ripple Current AC: 95mA
- Diameter: 5mm
- Height: 5.4mm
- Automotive Qualification Standard: -
- MSL: -
- SVHC: No SVHC (12-Jan-2017)
- Capacitance Tolerance: ± 20%
- Capacitance Tolerance ±: ± 20%
- Capacitor Case Style: Radial Can - SMD
- External Length / Height: 5.4mm
- External Width: 5.3mm
- Frequency Tolerance: 120Hz
- Impedance: 1.8ohm
- Impedance Frequency: 100kHz
- Impedance Temperature: 20°C
- Lead Cross-section Width: 0.65mm
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 1000h
- Power Factor: 0.26
- Power Factor Frequency: 120Hz
- Power Factor Temperature: 20°C
- Reel Quantity: 1000
- Ripple Current Frequency: 100kHz
- Ripple Current Temperature: 105°C
- Tape Width: 12mm
- Tolerance +: 20%
- Tolerance -: 20%
- Tolerance Temperature: 20°C
- Voltage Rating V DC: 6.3V
