CTB9308/2AO Terminal Block, Header, 2Pos, Th Camdenboss

CAMDENBOSSUGS :CTB9308/2AO Code de commande:1717022

Prix:
Prix ​​promotionnel€1,14

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (371 unité)

Documents et téléchargements

description

CAMDENBOSS - CTB9308/2AO - Terminal Block, Header, Header, 5.08 mm, 2 Ways, 12 A, 320 V, Through Hole Vertical

  • Pitch Spacing: 5.08mm
  • No. of Positions: 2Ways
  • Wire Size (AWG): 30AWG to 12AWG
  • Conductor Area CSA: 2.5mm²
  • Wire Connection Method: Push In
  • Rated Current: 12A
  • Rated Voltage: 320V
  • Product Range: CTB9308 Series
  • SVHC: No SVHC (15-Jan-2019)
  • Block Orientation: Through Hole Vertical
  • Cable Diameter Max: 2.5mm
  • Connector Mounting: PCB Mount
  • Connector Type: Terminal Block, PCB
  • Contact Material: Brass
  • Contact Plating: Nickel Plated Contacts
  • Gender: Header
  • Insulation Resistance: 5Mohm
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -20°C
  • Wire Size AWG Max: 12AWG
  • Wire Size AWG Min: 30AWG
  • Working Voltage: 380V
