EPCOS - B72205S0111K101 - TVS Varistor, 115 V, 150 V, B722 Series, 300 V, Disc 5mm, Metal Oxide Varistor (MOV)
- Voltage Rating VAC: 115V
- Voltage Rating V DC: 150V
- Product Range: B722 Series
- Clamping Voltage Vc Max: 300V
- Varistor Case Style: Disc 5mm
- Varistor Type: Metal Oxide Varistor (MOV)
- Peak Surge Current @ 8/20µs: 400A
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Peak Energy (10/1000uS): 3.6J
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: CECC, CSA, UL
- Body Diameter: 7mm
- Capacitance: 110pF
- Clamping Voltage: 300V
- Clamping Voltage @ 8/20µs Max: 300V
- External Length / Height: 9.5mm
- Height: 9.5mm
- Lead Length: 30mm
- Operating Temperature Range: -40°C to +85°C
- Peak Pulse Current IPP @ 8/20µs: 400A
- Suppressor Type: Varistor
- Surge Current: 400A
- Transient Energy: 3.4J
- Varistor Voltage: 180V
- Varistor Voltage @ 1mA: 162V
- Varistor Voltage @ 1mA Max: 198V
- Varistor Voltage Tolerance +: 10%
