B43504A9476M000 Cap, 47µF, 400V, Alu Elec, Snap In EPCOS

EPCOSUGS :B43504A9476M000 Code de commande:1219082

Prix:
Prix ​​promotionnel€6,75

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (633 unité)

Documents et téléchargements

description

EPCOS - B43504A9476M000 - Electrolytic Capacitor, Snap-in, 47 µF, 400 V, ± 20%, Snap-In, 3000 hours @ 105°C

  • Capacitance: 47µF
  • Voltage Rating: 400V
  • Product Range: B43504 Series
  • Lifetime @ Temperature: 3000 hours @ 105°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Quick Connect, Snap-In
  • Diameter: 22mm
  • Lead Spacing: 10mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Height: 25mm
  • ESR: 1.87ohm
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Category: IEC 384-4
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 25mm
  • Impedance: 2310mohm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +105°C
  • Operating life Time: 2000h
  • Ripple Current AC: 0.39A
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 400V
