ALS30A473MF063 Cap, 47000µF, 63V, Alu Elec, Screw Kemet

KEMETUGS :ALS30A473MF063 Code de commande:1572899

Prix:
Prix ​​promotionnel€59,42

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (66 unité)

Documents et téléchargements

description

KEMET - ALS30A473MF063 - Electrolytic Capacitor, Long Life, 47000 µF, 63 V, ± 20%, Screw, 19000 hours @ 85°C

  • Capacitance: 47000µF
  • Voltage Rating: 63V
  • Product Range: ALS30 Series
  • Lifetime @ Temperature: 19000 hours @ 85°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Screw
  • Diameter: 66mm
  • Lead Spacing: 28.5mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Height: 105mm
  • ESR: 0.008ohm
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • AC Ripple Current @ 100Hz: 26.7A
  • AC Ripple Current @ 10kHz: 26.5A
  • Capacitance Tolerance ±: ± 20%
  • Climatic Category: 40/085/56
  • ESR Frequency: 100Hz
  • ESR Temperature: 20°C
  • External Length / Height: 105mm
  • Leakage Current: 17766mA
  • Operating Life Temperature: 85°C
  • Operating Temperature Range: -40°C to +85°C
  • Operating life Time: 19000h
  • Ripple Current AC: 26.7A
  • Ripple Current Frequency: 100Hz
  • Ripple Current Temperature: 85°C
