ADP0204 SWITCH, DIL, PIANO, 2WAY TE CONNECTIVITY

TE CONNECTIVITYUGS :ADP0204 Code de commande:1264578

Prix:
Prix ​​promotionnel€2,83

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (470 unité)

Documents et téléchargements

description

TE CONNECTIVITY - ADP0204 - DIP / SIP Switch, 2 Circuits, Piano Key, Through Hole, SPST, 24 VDC, 100 mA

  • No. of Circuits: 2Circuits
  • Switch Actuator Style: Piano Key
  • Switch Mounting: Through Hole
  • Contact Configuration: SPST
  • Contact Voltage DC Max: 24VDC
  • Contact Current DC Max: 100mA
  • Product Range: AD Series
  • Switch Type: DIP Unsealed
  • SVHC: No SVHC (15-Jan-2019)
  • Actuation Type: Piano Key
  • Actuator Type: Piano Key
  • Colour: Black
  • Contact Resistance: 50mohm
  • Contact Voltage AC Max: 20VAC
  • Dielectric Strength VDC: 500VAC
  • External Depth: 8.79mm
  • External Length / Height: 6mm
  • External Width: 7.06mm
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 100Mohm
  • Insulation Resistance Voltage: 100VDC
  • Lead Spacing: 2.54mm
  • No. of Electrical Operations: 1000
  • No. of Mechanical Operations: 1000
  • No. of Positions: 2Ways
  • Operating Force Max: 800gf
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -30°C
  • Pin Configuration: DIL
  • Pitch Spacing: 2.54mm
  • Row Pitch: 8.13mm
  • Storage Temperature Max: 100°C
  • Storage Temperature Min: -45°C

Frais de port prévus
