TT ELECTRONICS / AB CONNECTORS - ABB00T 10SL3PSNB10SLRPG - Circular Connector, ABB, Wall Mount Receptacle, 3 Contacts, Solder Pin, Bayonet, 10SL-3
- Product Range: ABB Series
- Circular Connector Shell Style: Wall Mount Receptacle
- No. of Contacts: 3Contacts
- Circular Contact Type: Solder Pin
- Coupling Style: Bayonet
- Insert Arrangement: 10SL-3
- Connector Body Material: Aluminium Alloy Body
- Connector Body Plating: Olive Drab Chromate over Cadmium
- Contact Material: Copper Alloy
- Contact Plating: Silver
- Insert Rotation: N
- Service Class: Environmentally Sealed
- Equivalent Military Specification: MIL-DTL-5015 Series
- Approval Bodies: BS
- Cable Diameter Max: 2.77mm
- Cable Diameter Min: 1.68mm
- Colour: Olive
- Current Rating: 10A
- Current per Power Contact Max: 10A
- External Length / Height: 29.5mm
- External Width: 25.7mm
- Height: 29.5mm
- IP / NEMA Rating: IP67
- No. of Mating Cycles: 500
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Panel Cutout Diameter: 16.13mm
- Panel Cutout Size: 18.2 mm
- Voltage Rating VAC: 350V
- Working Voltage: 350V
