TT ELECTRONICS / AB CONNECTORS - AB05 6027 10 07 SN00 - Circular Connector, AB05, Straight Plug, 7 Contacts, Solder Socket, Bayonet, 10-7
- Product Range: AB05 Series
- Circular Connector Shell Style: Straight Plug
- No. of Contacts: 7Contacts
- Circular Contact Type: Solder Socket
- Coupling Style: Bayonet
- Insert Arrangement: 10-7
- Connector Body Material: Aluminium Alloy Body
- Connector Body Plating: Olive Drab Chromate over Cadmium
- Contact Material: Brass
- Contact Plating: Gold
- Insert Rotation: N
- Service Class: Corrosion Resistant
- Equivalent Military Specification: MIL-DTL-26482 Series I
- Approval Bodies: BS
- Cable Diameter Max: 5.02mm
- Colour: Olive
- Contact Gender: Socket
- Contact Resistance: 5mohm
- Coupling Diameter: 21.8mm
- Current Rating: 5A
- External Length / Height: 51.33mm
- IP / NEMA Rating: IP67
- No. of Mating Cycles: 500
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Voltage Rating VAC: 700V
- Working Voltage: 700V
