BINDER - 99 9475 100 07 - Circular Connector, 710 Series, Cable Mount Plug, 7 Contacts, Solder Pin, Nylon (Polyamide) Body
- Product Range: 710 Series
- Circular Connector Shell Style: Cable Mount Plug
- No. of Contacts: 7Contacts
- Circular Contact Type: Solder Pin
- Coupling Style: -
- Connector Body Material: Nylon (Polyamide) Body
- Connector Body Plating: -
- Contact Material: Brass
- Contact Plating: Gold
- SVHC: Lead (27-Jun-2018)
- Cable Diameter Max: 5mm
- Cable Diameter Min: 3mm
- Connector Mounting: Cable Mount
- Connector Type: Circular Industrial
- Contact Gender: Pin
- Contact Plating: Gold Plated Contacts
- Contact Resistance: 3mohm
- Contact Termination: Solder
- Contact Termination Type: Solder
- Current Rating: 4A
- Current per Contact Max: 4A
- Flammability Rating: UL94V-0
- Gender: Plug
- IP / NEMA Rating: IP40
- Insulation Resistance: 10ohm
- No. of Mating Cycles: 500
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Panel Cutout Size: 10.1 mm
- Voltage Rating VAC: 125V
- Wire Area Size Max: 0.25mm²
- Withstand Voltage: 1500V
- Working Voltage: 125V
