BELDEN - 9539 060U500 - Multicore Cable, Computer, Screened, 9 Core, 24 AWG, 0.2 mm², 498.69 ft, 152.4 m
- Cable Shielding: Screened
- No. of Cores: 9Core
- Wire Gauge: 24AWG
- Conductor Area CSA: 0.2mm²
- Reel Length (Imperial): 498.69ft
- Reel Length (Metric): 152.4m
- Jacket Colour: Chrome
- No. of Max Strands x Strand Size: 7 x 0.2mm
- Conductor Material: Copper
- Jacket Material: PVC
- External Diameter: 6.2mm
- Voltage Rating: 300V
- Product Range: -
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CSA, SRPVC, UL
- Belden Type Number: 9539
- Cable Type: Foil Shield
- Cable UL Style Number: UL2464
- Conductor Make-up: 7 / 32AWG
- Current Rating: 1.75A
- Operating Temperature Max: 80°C
- Operating Temperature Min: -30°C
- Outer Diameter: 6.2mm
- Screen Type Primary: Aluminium Polyester
- Secondary Insulation Colour: Chrome
- Secondary Insulation Material: PVC
- Wire Size: 24AWG
