9537 060U500 Cable, 9537, 7CORE, 153M Belden

BELDENUGS :9537 060U500 Code de commande:1182159

Prix:
Prix ​​promotionnel€501,80

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (5 unité)

Documents et téléchargements

description

BELDEN - 9537 060U500 - Multicore Cable, Computer, Screened, 7 Core, 24 AWG, 0.2 mm², 498.69 ft, 152.4 m

  • Cable Shielding: Screened
  • No. of Cores: 7Core
  • Wire Gauge: 24AWG
  • Conductor Area CSA: 0.2mm²
  • Reel Length (Imperial): 498.69ft
  • Reel Length (Metric): 152.4m
  • Jacket Colour: Chrome
  • No. of Max Strands x Strand Size: 7 x 0.2mm
  • Conductor Material: Tinned Copper
  • Jacket Material: PVC
  • External Diameter: 5.31mm
  • Voltage Rating: 300V
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: CSA, SRPVC, UL
  • Belden Type Number: 9537
  • Cable Type: Foil Shield
  • Cable UL Style Number: UL2464
  • Conductor Make-up: 7 / 32AWG
  • Current Rating: 1.75A
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -30°C
  • Outer Diameter: 5.31mm
  • Screen Type Primary: Aluminium Polyester
  • Secondary Insulation Colour: Chrome
  • Secondary Insulation Material: PVC
  • Wire Size: 24AWG
