SENSATA/CRYDOM - 84137011 - Solid State Relay, 25 A, 280 VAC, Panel Mount, Screw, Zero Crossing
- Contact Configuration: -
- Load Current: 25A
- Operating Voltage Max: 280VAC
- Relay Mounting: Panel
- Relay Terminals: Screw
- Switching Mode: Zero Crossing
- Operating Voltage Min: 24VAC
- Control Voltage Min: 90VAC
- Control Voltage Max: 280VAC
- Product Range: GN Series
- SVHC: No SVHC (12-Jan-2017)
- Control Current Max: 10mA
- Control Current Min: 5mA
- Control Voltage AC Max: 280VAC
- Control Voltage AC Min: 90VAC
- Control Voltage DC Max: 280VDC
- Control Voltage DC Min: 90VDC
- Control Voltage Range: 90V AC to 280V AC
- Control Voltage Type: AC
- Dropout Voltage Vdo: 10VAC
- Isolation Voltage: 4kV
- Load Current Min: 100mA
- Load Current RMS Max: 25A
- Operating Frequency Max: 63Hz
- Operating Frequency Min: 47Hz
- Operating Temperature Max: 80°C
- Operating Temperature Min: -20°C
- Operating Voltage Range: 24V AC to 280V AC
- Output Type: Thyristor
- Output Voltage Max: 280VAC
- Output Voltage Min: 24VAC
- RMS Load Current Min: 50mA
- RMS Load Voltage Max: 280V
- RMS Load Voltage Min: 24V
- Single Cycle Surge Current: 500A
