71922-116LF Header, Right Angle, 16WAY Amphenol ICC

AMPHENOL ICCUGS :71922-116LF Code de commande:1103947

Prix:
Prix ​​promotionnel€3,97

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (720 unité)

Documents et téléchargements

description

AMPHENOL COMMUNICATIONS SOLUTIONS - 71922-116LF - Pin Header, Right Angle, Wire-to-Board, 2.54 mm, 2 Rows, 16 Contacts, Through Hole Right Angle

  • Pitch Spacing: 2.54mm
  • No. of Contacts: 16Contacts
  • Gender: Header
  • Product Range: Quickie Series
  • Contact Termination Type: Through Hole
  • No. of Rows: 2Rows
  • Contact Plating: Gold Plated Contacts
  • Contact Material: Phosphor Bronze
  • SVHC: No SVHC (15-Jan-2019)
  • Colour: Grey
  • Current Rating: 1A
  • Cut Thickness for PCBs Max: 1.6mm
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 100000Mohm
  • No. of Mating Cycles: 250
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -65°C
  • PCB Hole Diameter: 1mm
  • Polarisation Type: Bump/Clip
  • Withstand Voltage: 1000V
