6-1393243-1 Relay, DPDT, 250VAC, 8A SCHRACK - Te Connectivity

SCHRACK - TE CONNECTIVITYUGS :6-1393243-1 Code de commande:2060839

Prix:
Prix ​​promotionnel€7,89

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (495 unité)

Documents et téléchargements

description

SCHRACK - TE CONNECTIVITY - 6-1393243-1 - Power Relay, DPDT, 6 VDC, 8 A, RT2, Through Hole, Non Latching

  • Contact Configuration: DPDT
  • Coil Voltage: 6VDC
  • Contact Current: 8A
  • Product Range: RT2 bistable Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 90ohm
  • SVHC: No SVHC (15-Jan-2019)
  • Coil Voltage VDC Nom: 6V
  • Contact Current Max: 8A
  • Contact Voltage AC Nom: 250V
  • External Depth: 29mm
  • External Height: 15.7mm
  • External Width: 12.7mm
  • Nom Operating Power: 400mW
  • Relay Type: Power
