MOLEX - 38630-7806 - PCB Mount Barrier Terminal Block, 11.13 mm, 1 Row, 6 Ways, 24 AWG, 12 AWG, 25 A
- Pitch Spacing: 11.13mm
- No. of Rows: 1 Row
- No. of Positions: 6Ways
- Wire Size AWG Min: 24AWG
- Wire Size AWG Max: 12AWG
- Rated Current: 25A
- Rated Voltage: 600V
- Product Range: 38630 Series
- Approval Bodies: CSA, UL
- Colour: Black
- Connector Mounting: PCB Mount
- Connector Type: Terminal Block, Barrier
- Contact Material: Brass
- Contact Plating: Tin Plated Contacts
- Flammability Rating: UL94V-0
- Insulation Resistance: 5000Mohm
- No. of Rows: 1Rows
- Operating Temperature Max: 110°C
- Voltage Rating VAC: 600V
- Wire Area Size Max: 3.3mm²
- Withstand Voltage: 10500V
- Working Voltage: 600V
