WIELAND ELECTRIC - 25.195.1053.0 - Standard Terminal Block, Wire to Board, 8593, 10 Contacts, 3.5 mm, Terminal Block, PCB, PCB Mount
- Product Range: 8593 Series
- No. of Contacts: 10Contacts
- Pitch Spacing: 3.5mm
- Connector Type: Terminal Block, PCB
- Connector Mounting: PCB Mount
- Wire Size AWG Max: 16AWG
- Wire Size AWG Min: 30AWG
- Contact Plating: Tin Plated Contacts
- Contact Material: Bronze
- SVHC: No SVHC (12-Jan-2017)
- Block Orientation: Through Hole Right Angle
- Conductor Area CSA: 1.5mm²
- No. of Positions: 10Ways
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Rated Current: 10A
- Rated Voltage: 300V
- Voltage Rating VAC: 160V
- Wire Area Size Max: 1mm²
- Wire Connection Method: Screw
